Part Number: 58130

Maximum Extended Height: 9.5″

• Compressed Height: 4.25″

• Maximum Diameter: 5.4″

• Maximum Load at 100 PSI: 1,216 lbs.

• Design Height: 6.5-8.5″

• Air Fitting Size: 1/4″

• Top Fastener: 3/8″ – 24

• Bottom Fastener: 3/8″ – 16

• Mounting Hole Center: 2.75″ – Top/Center/Bottom
