Part Number: 49S36-07000

Description: Stock Location MHI TF06-18K Performance Turbo

Fitment: 08-15 Mitsubishi Lancer Evolution X

Details:

Mitsubishi's OE high-performance bolt-on turbo upgrade for the Evolution X 4B11T will help you go faster while not sacrificing quality and reliability. Manufactured to OEM standards by Mitsubishi Heavy Industries (MHI), TF06-18K is designed for an ideal blend of response and top-end power in the stock frame. The billet 18KX3RC compressor wheel utilizes the latest-generation blade aero with 7 primary blades and 7 splitter blades for a max flow rate of 54lb/min. The wastegate actuator is MHI's high-pressure 18PSI actuator. Now in its third year and achieving cult status, this simple and stock-appearing turbo consistently outperforms many higher-dollar setups.

Compressor Specifications:

• Compressor Type: Forged-Milled Wheel (FMW) Billet

• Compressor Wheel OD (exducer): 75mm

• Compressor Wheel Inducer: 55.1mm

• Max Flow Rate: 54 lb/min

• Compressor Housing: 3" hose coupler inlet, 2 bolt evoX outlet

Turbine Specification:

• Turbine type: 9-blade TF06 Inconel 713C Turbine Wheel

• Turbine Wheel Inducer: 61.5mm

• Turbine Wheel Exducer: 54mm
